IIYAMA 105" LH10551UWS-B1AG 5K UWD (5120x2160) IPS 21:9 Signage 24/7, 500 cd/m2, 1200:1 non Android, OPS-slot

05” Professional 5KUW Display for specialised 21:9 panoramic commercial signage

Experience a true 21:9 Panoramic Ultra-Wide view for all your content with the jaw dropping 105” displays of iiyama. This super sleek thin bezel design display shows vibrant and larger than life imagery and videos using 5KUW resolution to make the difference.

Whether installed in mission critical control room facilities or vibrant digital signage for high end retail spaces, this iiyama 105” large format display offers businesses an easy and effective solution to help capture their audience's attention. Designed to perform in continual, around the clock environments, the LH10551UWS-B1AG can be installed and utilised in landscape and portrait orientation to create the most stimulating imagery in any space.

DISPLAY CHARACTERISTICS
Design Thin bezel
Diagonal 104.7", 265.9cm
Panel IPS, AG coated glass, matte finish, haze 25%
Native resolution 5120 x 2160 @60Hz (14.75 megapixel, 5KUW)
Aspect ratio 21:9
Panel brightness 500 cd/m2
Static contrast 1200:1
Response time (GTG) 8ms
Viewing zone horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Colour support 1.07G (8 Bits+FRC) (NTSC 85%)
Horizontal Sync 30 - 140kHz
Viewable area W x H 2450 x 1033.6mm, 96.5 x 40.7"
Pixel pitch 0.479mm
Bezel colour and finish black, matte
INTERFACES / CONNECTORS / CONTROLS
Digital signal input HDMI x1 (2.0, max. 3840x2160 @60Hz)
DisplayPort x1 (1.4, max. 5120x?2160 @60Hz)
USB-C x1 (2.0 (signal only), 5120x2160 @60Hz (DP 1.4 Alt mode))
Monitor control input RJ45 (LAN) x1 (Supports RS232c over Ethernet only)
Digital signal output DisplayPort x1 (1.4, max. 5120x?2160 @60Hz, SST (Single Stream Transport ) Screen Mirror)
Audio output S/PDIF (Optical) x1
Mini jack x1 (3.5mm)
Speakers 2 x 10W
HDCP v.2.2
USB HUB x4 (2.0)
FEATURES
Extra OPS PC Slot
Max. non-stop operating time 24/7
Anti image retention yes
Video wall / daisy chain Yes, Daisy Chain via DP-OUT (SST format)
Housing (bezel) metal
GENERAL
OSD languages EN, DE, FR, ES, IT, CN, RU, JP, CZ, NL, PL
Control buttons Menu, Up, Down, Volume +, Volume -, Mute, Power, Power Indicator, Remote Sensor
User controls picture (brightness, contrast, sharpness), Audio (treble, bass, balance, speakers, volume), OSD setup (language, OSD H-Position, OSD V-position, transparency, OSD timeout, OSD rotation), advanced settings (colour temp., custom colour temp., gamma), general settings (power management, LED, RC lock, picture format, factory reset), other settings (source input, DP-OUT mirror, LAN, SW version)
Plug&Play DDC2B
MECHANICAL
Orientation landscape, portrait
Fanless design yes
VESA mounting 1500 x 600mm
Operation temperature range 0°C - 40°C
Storage temperature range - 20°C - 60°C
MTBF 50.000 hours (excluding backlight)
ACCESSORIES INCLUDED
Cables power, HDMI, RS-232c
Guides quick start guide, safety guide
Other Stickers for screw holes, wire buckles
Remote control yes (batteries included)
POWER MANAGEMENT
Power supply unit internal
Power supply AC 100 - 240V, 50/60Hz
Power usage 247W typical, 0.5W stand by, 0.3W off mode
SUSTAINABILITY
Regulations CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA
Energy efficiency class (Regulation (EU) 2017/1369) G
REACH SVHC above 0.1%: Lead
DIMENSIONS / WEIGHT
Product dimensions W x H x D 2487.4 x 1070.6 x 99.1mm
Box dimensions W x H x D 2683 x 1407 x 339mm
Weight (without box) 60.14kg
Weight (with box) 88.7kg
EAN code 4948570121977
