IIYAMA 98" LH9875UHS-B2AG 4K UHD (3840x2160) IPS Signage 24/7, 500 cd/m2, 1200:1, Android OS, E-Share, iiSignage2

98" 4K UHD Professional Digital Signage display featuring Android OS, iiSignage2 and OPS PC slot

Choose non-stop high performance and uninterrupted reliability with the ideal all-in-one signage solution for mission critical environments. This 500cd/m2 high brightness display featuring on-board Android 11 OS offers a straightforward user experience, making content creation, management, and sharing a breeze. The OPS PC Slot provides an embedded PC option for total flexibility, security and control. WiFi enabled, the LH9875UHS-B2AG is ready for remote content delivery using your network or you can choose to utilise LAN control.

The on-board iiSignage2 (Content Management System) gives you total control of your messaging and advertising remotely and safely. The Signal FailOver feature ensures your content is always actively displayed through your choice of inputs for mission critical environments. The built-in (and removable) WiFi module means this series is ready for remote content delivery using your network.

With iiControl (DMS), iiShare and the integrated EShare app (wireless screen sharing) you bring effortless ideation and efficient collaboration in your enterprise or school. You can start sharing wirelessly easier than ever before.

Its versatile orientation, sleek design, and 24/7 reliability ensures seamless integration into any business environment. Whether it's used in retail, corporate, hospitality, or educational settings, the LH9875UHS-B2AG will undoubtedly captivate your audience and leave a lasting impression.

DISPLAY CHARACTERISTICS
Design Thin bezel
Diagonal 97.5", 247.7cm
Panel , haze 25%
Native resolution 3840 x 2160 @60Hz
Aspect ratio 16:9
Panel brightness 500 cd/m2
Static contrast 1200:1
Response time (GTG) 8ms
Viewing zone horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Colour support 1.07G (8 Bits+FRC)
Horizontal Sync 28 - 160kHz
Viewable area W x H 2159 x 1214mm, 85 x 47.8"
Bezel width (sides, top, bottom) 23mm, 23.25mm, 23.25mm
Pixel pitch 0.562mm
Bezel colour and finish black, matte
INTERFACES / CONNECTORS / CONTROLS
Analog signal input VGA x1 (DVI-I: VGA+DVI)
Digital signal input DVI x1
HDMI x3
DisplayPort x1
Audio input Mini jack x1
Monitor control input RS-232c x1
RJ45 (LAN) x1
IR x1
Digital signal output DisplayPort x1
Audio output Mini jack x1
Speakers 2 x 16W
Monitor control output RS-232c x1
IR loop through x1
HDCP yes
USB ports x2
FEATURES
Integrated software Android 11 OS, iiSignage2, iiControl, iiShare, FailOver, EShare
WiFi yes (Built-in, 2.4G/ 5G)
Hardware CPU: A73*4+A53*4, GPU: Mali G52 MP8, RAM: 4GB, ROM: 32GB
Extra OPS PC Slot, micro SD card slot, Wall mounting kit included (VESA 800x600mm)
Max. non-stop operating time 24/7
Anti image retention yes
Media playback yes
Housing (bezel) metal
GENERAL
OSD languages EN, DE, FR, ES, IT, CN, RU, JP, CZ, NL, PL, SV, FI, DA, NB
Control buttons Power, Mute, Input, Volume +, Volume -, Up, Down, Menu
User controls picture (brightness, contrast, sharpness, black level, tint, colour, noise reduction, gamma selection, colour temperature, colour control, over scan, picture reset), screen (H. position, V. position, clock, clock phase, zoom mode, custom zoom, auto adjust, screen reset), Audio (balance, treble, bass, volume, audio out, maximum volume, minimum volume, mute, audio source, audio reset, audio out sync, speaker setting), configuration 1 (switch on state, panel saving, RS232-routing, boot on source, WOL, configuration 1 reset, factory reset), Configuration 2 (OSD timeout, OSD H-Position, OSD V-position, rotation, information OSD, logo and animation, logo setting, animation setting, monitor ID, group ID, monitor information, DP version, DP monitors, HDMI version, configuration 2 reset), advanced option (IR control, power LED light, keyboard control, tiling, off timer, schedule, HDMI with one wire, HDMI with one wire power off, FailOver, language, OSD transparency, power saving, OPS PC settings, advanced option reset), Android settings (network & internet, apps & notifications, display, signage display, security, language & input, date & time, about device)
Plug&Play DDC2B
MECHANICAL
Orientation landscape, portrait
Fanless design yes
VESA mounting 800 x 600mm
Operation temperature range 0°C - 40°C
MTBF 50.000 hours (excluding backlight)
ACCESSORIES INCLUDED
Cables power (1.8m), HDMI (1.8m), RS-232c (1.8m)
Guides quick start guide, safety guide
Other Wall mount bracket MD-WM8060, Wall mount guide, Screws, Screw anchors, Stickers for screw holes
Remote control yes (batteries included)
POWER MANAGEMENT
Power supply unit internal
Power supply AC 100 - 240V, 50/60Hz
Power usage 173W typical, 0.5W stand by, 0.3W off mode
SUSTAINABILITY
Regulations CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA
Energy efficiency class (Regulation (EU) 2017/1369) F
REACH SVHC above 0.1%: Lead
DIMENSIONS / WEIGHT
Product dimensions W x H x D 2204.9 x 101.7 x 1260.4mm
Box dimensions W x H x D 2360 x 280 x 1400mm
Pallet volume 4pcs
Pallet dimensions W x H x D 2360 x 1140 x 1566mm
Weight (without box) 77.8kg
Weight (with box) 102.6kg
EAN code 4948570124923
